Products

RF & Microwave Amplifiers

Features

    • Frequency Range Covering 1-40 GHz
    • Variety of Gain and Power Available
    • Excellent Gain Flatness & Good VSWR
    • Compact and Ruggedized Packaging
    • Package Options: Drop-in, SMA/2.9mm & SMP

Microwave Amplifier Assemblies

Features

    • Wide Band Frequency Coverage 1 to 40 GHz
    • Multi-channel Switchable Input Control
    • Ruggedized Packaging Options

Ruggedized Switchable Input Coaxial Amplifier

Features

    • Wide Band Frequency Coverage
    • Fast Switchable Input Control ≤ 100 nS
    • Internal DC Regulation
    • EAR99 Export Classification

Compact RF & Microwave High Speed SDLVAs

Features

    • Wide Frequency Range Coverage 2-18 GHz
    • Excellent Log Linerity over -70 to 0 dbm
    • Fast Rise Time of ≤ 10 ns
    • Fast Recovery Time of ≤ 60 ns
    • Compact and Ruggedized Packaging
    • EAR 99 Export Classification

Fast Rise & Fall Time SDLVA
2 - 18 GHz; 60 dB

Features

    • FAST RISE AND FALL TIMES
    • EXCELLENT LINEARITY
    • COMPUTER TUNED AND TESTED
    • PRODUCTION READY
    • SIZE: 3.20” x 1.85” x 0.40”

High Speed SDLVAs with Limited RF Output

Features

    • Limited RF Output
    • Flat Frequency Response
    • Excellent Log Linearity
    • Excellent Temperature Performance
    • DC Coupled
    • EAR 99 Export Classification

Wilkinson Microwave Power Dividers/ Power Combiners

Features

    • Low Insertion Loss
    • High Isolation between Output Ports
    • Excellent Amplitude Balance and Phase Balance
    • Wide Band Frequency Coverage
    • Compact and Ruggedized Packaging
    • Package Options: Drop-In, SMA/2.9mm & SMP

18 - 40 GHz SDLVA

Features

    • 18 - 40 GHz
    • -63 TO +2 dBm Video Log Range
    • 15 nS Rise Time (max)
    • +/- 1.5 dB Video Log linearity
    • 40 nS Fall Time(typ)
    • 10 nS Delay Time
    • Optional Limited RF Output
    • EAR 99 Export Classification

DC - 40 GHz Resistive Power Dividers/ Combiners

Features

    • Low Insertion Loss
    • Excellent Amplitude Balance and Phase Balance
    • Wide Band Frequency Coverage
    • Compact and Ruggedized Packaging
    • Package Options: SMA, 2.9mm

High Speed SDLVAs

Features

    • 0.5 - 18 GHz Frequency Coverage
    • 10 nS Rise Time
    • 60 nS Recovery Time
    • Excellent Log Linearity
    • Flat Frequency Response
    • EAR 99 Export Classification

10 - 40 GHz Wilkinson Power Dividers/ Combiners

Features

    • Low Insertion Loss
    • Excellent Amplitude Balance and Phase Balance
    • Wide Band Frequency Coverage
    • Compact and Ruggedized Packaging
    • Package Options: 2.9mm

Log IF Amplifiers

Features

    • Wide Dynamic Range Coverage
    • Low DC Power Consumption
    • Fast Rise and Fall Times
    • Excellent Absolute Accuracy
    • Compact Ruggedized Package
    • EAR 99 Export Classification



Log IF Amplifiers with
Limited RF Output

Features

    • Limited RF Output
    • Wide Dynamic Range
    • Flat Frequency Response Over 0.5 - 2 GHz
    • Excellent Log Linearity
    • Low Log Slope Variation
    • Excellent VSWR
    • EAR 99 Export Classification

Compact Combline Band Pass Filters

Features

    • Low Passband Insertion Loss < 1.0 - 6.0 dB typ
    • High Skirt Rejection > 35 - 60 dB typ
    • Ruggedized & Lightwieght Construction
    • Various Packaging Options Available
    • EAR 99 Export Classification



RF & Microwave Switches

Features

    • Low Insertion Loss
    • High Isolation
    • Wide Band Frequency Coverage
    • Compact and Ruggedized Packaging
    • Package Options: Drop-In, SMA/2.9mm & SMP

Compact Multiplexer Filters

Features

    • Variety of Frequency Ranges Available
    • Low Passband Insertion Loss ≤ 1.5 - 4.5 dB typ
    • High Skirt Selectivity ≥ 45 - 60 dB typ
    • Compact Packaging Options
    • EAR 99 Export Classification

Combline Filters

Features

    • EXCELLENT REJECTION AND SPURIOUS
    • LOW PASS BAND INSERTION LOSS
    • LIGHTWEIGHT, COMPACT AND ECONOMICAL
    • ROBUST CONSTRUCTION

Ruggedized Microwave Gain Equalizers

Features

    • Broad Frequency Coverage 2-18 GHz
    • Variety of Negative Gain Slopes
    • Low Ripple and VSWR
    • Compact and Ruggedized Packaging
    • Package Options: Drop-In, SMA/2.9mm & SMP

Switching Matrix 6.0 - 18.0 GHz

Features

    • 3 x 6 MATRIX
    • HIGH SPEED ABSORPTIVE SWITCHES
    • MULTIPLE CROSSOVERS
    • 6 dB NOISE FIGURE
    • 20 nS RECOVERY TIME
    • 70 dB ISOLATION

Switching Matrix 2.0-18.0 GHz

Features

    • 10 x 6 MATRIX
    • HIGH SPEED ABSORPTIVE SWITCHES
    • MULTIPLE AMPLIFIERS, SWITCHES, POWER DIVIDERS
    • 20 nS RECOVERY TIME
    • 65 dB ISOLATION BETWEEN ANY TWO PORTS

0.5 - 18.0 GHz Switch Matrix (16 x 12)

Features

    • 0.5 - 18.0 GHz Frequency Range
    • +/- 8° deGREES Phase Tracking
    • 15 dBm Operating Input Power
    • 50 nS Switching Speed (10/90% RF)
    • -40 C° to +71 C° Operating Temperature

Switch Filter Bank 6.0 - 18.0 GHz

Features

    • 8 CHANNELS
    • MMIC SWITCH DESIGN
    • SHARP FILTER REJECTION:
    • 60 dBc; 15% FROM BAND EDGES
    • HIGH SWITCH ISOLATION: 62 dB

6 - 18 GHz Switch Filter Bank

Features

    • EXTREMELY COMPACT SIZE
    • 6 - 18 GHZ FREQUENCY RANGE
    • 8 CHANNELS
    • MMIC SWITCH DESIGN
    • SHARP FILTER REJECTION
    • HIGH ISOLATION
    • 100 NS (NOM) SWITCHING SPEED

Compact and Ruggedized Microwave Fixed Attenuators

Features

    • Wide Frequency Range Covering 0.5 to 40 GHz
    • Excellent Attenuation Accuracy +/- 0.25 dB
    • Excellent VSWR ≤ 1.25:1 Typical
    • Compact and Ruggedized Packaging
    • Package Options: Drop-In, SMA/2.9mm & SMP

Phase Matched Receiver for Interferometer DF Systems
2.0 - 8.0 GHz and 8.0 - 18.0 GHz

Features

    • MULTI-OCTAVE FREQUENCY COVERAGE
    • 90 dB TEMPERATURE COMPENSATED AND
    • PHASE MATCHED GAIN FOR LIMITED RF OUTPUT
    • BUILT-IN LIMITER AND BITE SWITCH
    • +/- 15° PHASE MATCH AT 18 GHz

Integrated ECM Receiver
6.0 - 18.0 GHz

Features

    • ULTRA BROAD FREQUENCY RANGE
    • BUILT-IN HIGH POWER PROTECTION
    • BUILT-IN BITE CIRCUIT
    • BUILT-IN DLVA
    • RF OUTPUT FOR FREQUENCY MEASUREMENT
    • EXCELLENT LINEARITY

Digitally Controlled Attenuator
0.5 - 18.0 GHz

Features

    • 0.5 - 18.0 GHz FREQUENCY RANGE
    • TTL COMPATIBLE LOGIC
    • HIGH SPEED SWITCHING
    • LOW DC POWER CONSUMPTION
    • STABLE ATTENUATION
    • HIGH RF POWER HANDLING
    • SIZE: 2.0” x 2.0” x 0.45”

5-Channel Channelized Receiver Front End
1.0 - 18.0 GHz

Features

    • 1.0 - 18.0 GHz COVERED IN 5 BANDS
    • RF OUTPUT FOR FREQUENCY MEASUREMENT
    • 65 dB CHANNEL TO CHANNEL ISOLATION
    • FILTER SKIRT -60 dBc; 15%
    • 70 dB DLVA FOR AMPLITUDE MEASUREMENT
    • T.S.S.: -75 dBm
    • -72 dBm TO 0 dBm LOG RANGE
    • ABSOLUTE ACCURACY PER CHANNEL: +/- 2.0 dB
    • MATCHING BETWEEN CHANNELS: 2.0 dB P-P

0.5 - 40 GHz Front End Amplifier/ Front End Receiver

Features

    • 0.5 - 40.0 GHz INPUT FREQUENCY
    • 0.5 - 18.0 GHz OUTPUT FREQUENCY
    • 22 dB GAIN
    • +/- 2.5 dB GAIN FLATNESS
    • UP TO 50 dBm MAX INPUT POWER (DAMAGE)
    • TOTAL WEIGHT: 1.74 Kg
    • 6.5 x 4.0 x 1.85 INCHES
    • LO’s BUILT-IN

X-Band Phase Shifter 8.0 - 8.4 GHz

Features

    • 8.0 - 8.4 GHz FREQUENCY RANGE
    • HIGH RELIABILITY
    • 20 dB POWER GAIN
    • EXCELLENT GAIN FLATNESS
    • LOW INSERTION LOSS
    • 4 DEGREES PHASE ACCURACY
    • SIZE: 3.0” x 2.5” x 0.79"

Digital Frequency Discriminator
4.3-5.3 GHz

Features

    • 4.3 - 5.3 GHz FREQUENCY RANGE
    • HIGH SENSITIVITY
    • MULTIPLE SIGNAL HANDLING
    • TTL COMPATIBLE
    • 300 nS PROCESSING TIME
    • 0.25 MHz FREQUENCY ACCURACY

Digital Frequency Discriminator
239-386 MHz

Features

    • 239 - 386 MHz FREQUENCY RANGE
    • HIGH SENSITIVITY
    • MULTIPLE SIGNAL HANDLING
    • TTL COMPATIBLE
    • 300 nS PROCESSING TIME
    • 1 MHz FREQUENCY ACCURACY
    • BUILT-IN SDLA

2 - 6 GHz Digital Frequency Discriminator

Features

    • 2.0 - 6.0 GHz FREQUENCY RANGE
    • 100 nS to CW INPUT RF PULSE  WIDTH
    • EXTERNALLY TRIGGERED
    • 14 BITS FREQUENCY RESOLUTION
    • 100 nS RECOVERY TIME
    • SIZE: 5.9” x 4.69” x 1.5”

6 -18 GHz Digitally Frequency Discriminator

Features

    • 6.0 - 18.0 GHz FREQUENCY RANGE
    • 100 nS to CW INPUT RF PULSE  WIDTH
    • EXTERNALLY TRIGGERED
    • 14 BITS FREQUENCY RESOLUTION
    • 100 nS RECOVERY TIME
    • SIZE: 5.9” x 4.69” x 1.5”

2 - 18 GHz Digital Frequency Discriminator

Features

    • 2.0 - 18.0 GHz FREQUENCY RANGE
    • HIGH SENSITIVITY -60 dBm
    • MULTIPLE SIGNAL HANDLING
    • TTL COMPATIBLE 14 BIT OUTPUT
    • 300 nS PROCESSING TIME
    • 5.0 MHz FREQUENCY ACCURACY
    • 1.0 MHz FREQUENCY RESOLUTION

RF & Microwave Detectors

Features

    • Tunnel, Schottky, and Zero Bias Schottky
    • Excellent Sensitivity, TSS of - 50 dBm
    • K Factor Ranges from 700 to 4000 mV/dB
    • Wide Band Frequency Coverage
    • Compact  and Ruggedized Packaging
    • Package Options: Drop-In, SMA, & SMP

6 - 18 GHz Matched ESM ECM Subsystem

Features

    • 6 - 18 GHz FREQUENCY RANGE
    • COMPLEMENTARY MATCHED Rx & Tx MODULES
    • RF PROCESSOR & DRFM DIRECT INTERFACE
    • HIGH SENSITIVITY
    • HIGH DYNAMIC RANGE
    • FOR MILITARY TACTICAL ENVIRONMENT

9.5 - 18.5 GHz Fast Stepping LO/High Speed Synthesizer

Features

    • EXTREMELY HIGH SPEED: 70 ns
    • 500 MHz STEP SIZE VARIABLE OUTPUT
    • FIXED 5.5 GHz OUTPUT
    • 5 BITS SINGLE ENDED TTL CONTROL
    • +/- 8V POWER SUPPLY
    • EXTERNAL REFERENCE INPUT OPTION
    • HIGH STABILITY OCXO
    • FREQUENCIES GENERATED BY DIRECT MULTIPLICATION, MIXING, FILTERING AND SWITCHING
    • MULTIPLE OUTPUTS CAN DRIVE MULTIPLE TUNERS

2 - 18 GHz Matched ESM ECM Subsystem

Features

    • 2 - 18 GHz FREQUENCY RANGE
    • COMPLEMENTARY MATCHED Rx & Tx MODULES
    • RF PROCESSOR & DRFM DIRECT INTERFACE
    • HIGH SENSITIVITY
    • HIGH DYNAMIC RANGE
    • FOR MILITARY TACTICAL ENVIRONMENT

High Speed RF Source 6.0-18.0 GHz

Features

    • 6.0 - 18.0 GHz FREQUENCY RANGE
    • 100 nS RESPONSE TIME
    • TTL INTERFACE
    • AMPLITUDE CONTROL OVER 60 dB
    • HARMONICS -20 dBc (-60 dBc WITH  SFB)
    • LOW PHASE NOISE
    • 100 MHz STEP SIZE
    • CRYSTAL REFERENCE

0.4 - 18.0 GHz Pre-Channelized Single Conversion, IF B.W 2.0-6.0 GHz Miniature Tuner

Features

    • TYPE 2 TUNER
    • 0.4 - 18.0 GHz INPUT FREQUENCY RANGE
    • PRE-FILTERED TO AVOID HARMONICS
    • 2.0 - 6.0 GHz OUTPUT
    • 21 dB TOTAL GAIN
    • OUTPUT AMPLIFIER WITH +20 dBm OUTPUT POWER
    • SIZE: 6.8” x 5.1” x 1.0”

Microwave Assembly 1.0 - 18.0 GHz

Features

    • TYPE 1 TUNER
    • 65 dB INSTANTANEOUS DYNAMIC RANGE
    • -65 dBm CHANNEL SENSITIVITY
    • PRECONVERSION CHANNELS: 8 EACH;
    • -65 dBc; 15% FROM BAND EDGES
    • -60 dB CHANNEL TO CHANNEL ISOLATION
    • BUILT-IN 65 dB LOG VIDEO OUT @ 1.0GHz

Wideband Microwave Tuner
1 - 18.0 GHz

Features

    • TYPE 1 TUNER
    • 1 - 18 GHz INPUT FREQUENCY
    • 65 dB INPUT DYNAMIC RANGE
    • 4 INPUT CHANNELS
    • 77.6 WATTS POWER CONSUMPTION
    • SIZE: 9.2” x 5.9” x 1.7”
    • WEIGHT 3.0 KG

Tuner/Downconverter
2 - 6 GHz to 1 - 2 GHz Baseband

Features

    • TYPE 1 TUNER
    • 2.0 - 6.0 GHz INPUT FREQUENCY
    • 1.0 - 2.0 GHz IF OUTPUT
    • 25 dB IF OUT NET GAIN
    • HERMETIC PACKAGE OPTIONS AVAILABLE
    • EXCELLENT TEMPERATURE STABILITY
    • SIZE: 4.98” x 3.42” x 0.89”



Tuner/Downconverter
6.0 - 18.0 GHz to 2.0 - 6.0 GHz Baseband

Features

    • TYPE 1 TUNER
    • 6.0 - 18.0 GHz INPUT FREQUENCY
    • 2.0 - 6.0 GHz IF OUTPUT
    • -10 dBm LO INPUT
    • 200 NS SWITCHING SPEED
    • 6.0 - 18.0 GHz AUXILIARY OUTPUT
    • -30 dBc INBAND SPURIOUS

Four Channel 0.5 - 18.0 GHz ESM System Converter

Features

    • 0.5 - 18.0 GHz FREQUENCY RANGE
    • FOUR IF OUTPUTS
    • 1.0 GHz IF CENTER FREQUENCY
    • 100 ns SWITCHING TIME
    • EXTERNAL VARIABLE LO
    • BUILT-IN LO1 PROCESSING
    • BUILT-IN LO2
    • INTEGRATED DC-DC CONVERTER/ POWER SUPPLY
    • LO PRESENCE MONITOR
    • CHANNEL TEMPERATURE MONITORING
    • MODULAR DESIGN

0.8 - 20.0 GHz Pre-Channelized Dual Conversion Selectable IF Bandwidth Miniature Tuner

Features

    • TYPE 1 TUNER
    • 70 dB DYNAMIC RANGE
    • 8 PRECONVERSION CHANNELS
    • 50 dB SPURIOUS FREE RANGE
    • 5 dB CONVERSION GAIN
    • 60 dB CHANNEL TO CHANNEL ISOLATION
    • 1 GHz IF OUTPUT
    • +/- 25MHz, +/- 125MHz, +/- 250MHz INSTANTANEOUS BW

Fast Rise & Fall Time ERDLVAs
0.5 - 18 GHz; 75 dB

Features

    • Fast Rise and Fall Times
    • Excellent Linearity
    • Computer Tuned and Tested
    • Production Ready
    • EAR 99 Export Classification

0.5 to 18 GHz DLVAs with 45 dB Dynamic Range

Features

    • Broad Frequency Range Coverage
    • Small Size
    • Ruggedized Packaging
    • Fast Rise and Fall Times
    • Excellent Absolute Accuracy
    • Small Log Slope Variation
    • EAR 99 Export Classification

LO Assembly

Features

    • 4, 5 and 6 GHz FREQUENCY RANGES
    • < 200 KHz FREQUENCY ACCURACY
    • -9 dBm MIN OUTPUT POWER LEVEL
    • 2 Bit TTL CONTROL
    • -30 dBc MAX SPURIOUS LEVELS

Wide Band DLVA with 52 dB Dynamic Range

Features

    • Wide Frequency Range
    • Excellent Log Linearity
    • Low DC Power
    • MIL Screened & Hermetically Sealed
    • Computer Tuned and Tested
    • Size: 2.2” x 1.5” x 0.4”
    • EAR 99 Export Classification

LO Assembly with BITE Source

Features

    • FREQUENCY RANGE: 7.0 - 18.0 GHz
    • AMPLITUDE MATCHING:
    • PHASE MATCHING: < 7 Degree
    • TTL CONTROL: 1 BIT
    • INTERNAL OSCILLATOR: 1.0 GHz - 18 Ghz INTERNAL OSCILLATOR: 1.0 GHz - 18 Ghz

Customer Program

JPL - MIRO (Complex Integrated Microwave Assembly)
JPL - MLS (complex Converter Assembly)
AEG - Germany FL-1800 (Electronic Counter Measure)
CSIST - Shipboard Radar Update
Raytheon - SLQ - 32
BAE/Sanders - USM - 406C (Test Set)
BAE/Sanders - USM - 464 (Test Set)
US Navy - SAR - Synthetic Aperture Radar TR Modules
NAVSEA/Envisioneering - SEAPORT-e Program (Tuners)
Lockheed Martin - AEGIS
SEARAM - Rolling Airframe Missile
Brazilian Navy
DSTO Australia
Anaren - Canadian F18
Ford - HARM Missile Seeker
ITT - ASPJ (Airborne Self Protect Jammer) IDECM (Integrated Digital Electronic Counter)
Japan - FSX, Several RWR (Radar Warning Receiver)
BAE/Loral - ALR - 56C (F15 Fighter) RWR
BAE/Loral - ALR - 56M (F16 Fighter) RWR
BAE/Loral - ALQ - 131 (Pod Mounted Jammer)
Turkish F-16 - Front End Converters SPEWS II
DRS - Euro Fighter Test Set
BAE/Loral - ALR - 56V - F15 (RWR Update)
Northrop Grumman - JSTARS
Northrop Grumman - ALQ - 188 (Electronic Attack Training Pod)
Raytheon - ALQ - 142 (LAMPS Helicopter)
Electronica (Italy)
Government of India - Aircraft Radar
DSTO (Australia)
© Copyright 2017 Akoninc.
Design and Developed by AskOnlineSolutions
