DLVAs

Wide Band DLVA with 52 dB Dynamic Range

Features

    • Wide Frequency Range
    • Excellent Log Linearity
    • Low DC Power
    • MIL Screened & Hermetically Sealed
    • Computer Tuned and Tested
    • Size: 2.2” x 1.5” x 0.4”
    • EAR 99 Export Classification

Description

AKON introduces a DLVA with dynamic logging range of 40 dB covering 1.4 to 21.5 GHz frequency coverage. This DLVA has excellent log slope variation that results in excellent absolute accuracy. This new product offers performance at low DC power consumption. The product was designed with thin-film/thick-film hybrid technology, then packaged into a small hermetic enclosure.

AKON products are designed to withstand the demanding environments of Military, Space and Industrial applications. Our compact and ruggedized products are designed to handle stringent mechanical shock/vibrations, temperature cycling, altitude and temperature extremes.

Reliability is a key feature of AKON products and to ensure this we perform ESS testing on all of our products. AKON offers an off-the-shelf screening option called its “H“ series, per Mil-STD-883 level B that is available on all of its RF & Microwave Components. For custom electrical, mechanical, and screening options, please contact AKON Sales: sales@akoninc.com (or) 408-432-8039.

Model Number A15-ML074
Frequency Range(GHz) 1.4-21.5
T.S.S(dBm) -52
Logging Range (dBm) 52
Frequency Flatness(dB) +/- 1.5 dB @ 80% Band
+/- 1.75 dB @ 90% Band
+/- 2.0 dB @ 100% (max)
VSWR 3.0:1
Log Linearity (dB) +/- 0.75 dB (typ);
+/- 1.0 dB (max)
Log Slope (mV/dB) For Linerity Measurement 50
Rise Time (nS) 30 (max) any pulse width
Fall Time (nS) 250
Recovery Time (nS) (90% to +/- 1.0 dB of Baseline) 300 (typ)
500 (max)
Propagation Delay (nS) (50% RF to 10% Video) 60 (typ)
Power Supply Current (mA) -9 (VDC) 45
Power Supply Current (mA) +9 (VDC) 120
Coupling DC
Video Load (ohms) 93 +/-1
Size(Inches) 2.2” x 1.5” x 0.4”
Operating Temperature (°C) -40 to +85
Select Product
Note: You can select different models and submit inquiry or custom quote request with help of different options available at bottom of page.

AKON, Inc. and it’s affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
All products are measured in 50-ohm system, over a temperature Range of -40° to +85° C.
