Log IF Amplifiers

Log IF Amplifiers with Limited RF Output

Features

    • Limited RF Output
    • Wide Dynamic Range
    • Flat Frequency Response Over 0.5 - 2 GHz
    • Excellent Log Linearity
    • Low Log Slope Variation
    • Excellent VSWR
    • EAR 99 Export Classification

Description

AKON has developed a new series of Log IF Amplifiers that operate over a variety of bands between 0.5 to 2 GHz frequency range. This new line offers excellent linearity over a dynamic logging range of dB and comes with a compact ruggedized package.

AKON products are designed to withstand the demanding environments of Military, Space and Industrial applications. Our compact and ruggedized products are designed to handle stringent mechanical shock/vibrations, temperature cycling, altitude and temperature extremes.

Reliability is a key feature of AKON products and to ensure this we perform ESS testing on all of our products. AKON offers an off-the-shelf screening option called its “H“ series, per Mil-STD-883 level B that is available on all of its RF & Microwave Components. For custom electrical, mechanical, and screening options, please contact AKON Sales: sales@akoninc.com (or) 408-432-8039.

SPECIFICATIONS
Model Number A16-OH003 A16-1H004 A16-MH005
Frequency Range(GHz) 0.5-1 1-2 0.5-2
T.S.S(dBm) -72 -72 -72
Logging Range (dBm) -65 to 0 -65 to 0 -65 to 0
Frequency Flatness(dB) +/- 1.0 +/- 1.0 +/- 1.25
Limited Output (dB) +5 +/- 2.0 +5 +/- 2.0 +5 +/- 3.0
Harmonics (dBc) 8 (nom) 8 (nom) 8 (nom)
Log Linearity (dB) +/- 1.0 +/- 1.0 +/- 1.0
Temperature Variation (dB) +/- 1.0 +/- 1.0 +/- 1.0
Rise Time (nS) 10 10 10
Propagation Delay (nS) (50% RF to 10% Video) 10 10 10
Recovery Time (nS) (90% to +/- 1.0 dB of Baseline) 60 60 60
Log Slope (mV/dB) 15 15 15
Coupling DC DC DC
Operating Temperature (°C) -40 to +85 -40 to +85 -40 to +85
VSWR 2.0:1 2.0:1 2.0:1
Power SupplyCurrent (mA) +15 (VDC) +340 (typ) +340 (typ) +340 (typ)
Power SupplyCurrent (mA) -15 (VDC) -125 (typ) -125 (typ) -125 (typ)
Size Figure 1 Figure 1 Figure 1
Select Product
Note: You can select different models and submit inquiry or custom quote request with help of different options available at bottom of page.
