Fast Stepping LO Assemblies

LO Assembly with BITE Source

Features

    • FREQUENCY RANGE: 7.0 - 18.0 GHz
    • AMPLITUDE MATCHING:
    • PHASE MATCHING: < 7 Degree
    • TTL CONTROL: 1 BIT
    • INTERNAL OSCILLATOR: 1.0 GHz - 18 Ghz INTERNAL OSCILLATOR: 1.0 GHz - 18 Ghz

Description

AKON is a leading manufacturer of RF/ microwave components and subsystems for military, space and commercial applications. AKON’s line of products includes high reliability custom integrated microwave assemblies, DIFM receivers, microwave receiver front-ends, RF switching matrices, frequency synthesizers, custom LO Assemblies, frequency converters, RF Switches, RF attenuators and microwave amplifiers covering 2 - 18 GHz frequency range (up to 26.5 GHz for some applications). AKON is qualified to MIL-I-45208 Quality System Requirements by agencies of the US Department of Defense as well as several governmental space agencies. Screening to requirements of MIL-STD-883 are available at additional cost. All specifications described below are over the full operating temperature.

Model Number A20-MX173
J1/ J10 (GHz) RF/BITE IN 9 -16 (+10 dBm min)
J11 (GHz) RF Monitor 9 -16 (+6 dBm nom)
J12 (GHz) BITE Monitor 7 - 18 (-6 dBm nom)
J2, J3, J4, J5 (GHz) LO 9-16
Amplitude Matching (dB) 0.4
Phase Match (°) 7(nom)
J6, J7, J8, J9 (GHz) BITE 7 - 18 (-13 dBm nom)
SP2T Control (dB) 60 (min)
TTL Control (Bits) 1
Internal Oscillator (GHz) @ 1.0
Power Supply(VDC) +8 @ 350 mA
-8 @ 100 mA; 3.6 Watts
