18 - 40 GHz SDLVA

Features

    • 18 - 40 GHz
    • -63 TO +2 dBm Video Log Range
    • 15 nS Rise Time (max)
    • +/- 1.5 dB Video Log linearity
    • 40 nS Fall Time(typ)
    • 10 nS Delay Time
    • Optional Limited RF Output
    • EAR 99 Export Classification

Description

AKON has developed a new DLVA that operates from 18 to 40 GHz frequency range. This new DLVA has 65 dB dynamic logging range with a log accuracy of +/- 2 dB over 80% of the band. AKON’s DLVA has a fast rise time of 10 nS and a 40 nS fall time.

AKON products are designed to withstand the demanding environments of Military, Space and Industrial applications. Our compact and ruggedized products are designed to handle stringent mechanical shock/vibrations, temperature cycling, altitude and temperature extremes.

Reliability is a key feature of AKON products and to ensure this we perform ESS testing on all of our products. AKON offers an off-the-shelf screening option called its “H“ series, per Mil-STD-883 level B that is available on all of its RF & Microwave Components. For custom electrical, mechanical, and screening options, please contact AKON Sales: sales@akoninc.com (or) 408-432-8039.

Model Number A15-MCH212
Frequency Range(GHz) 18-40
T.S.S(dBm) -67 (nom)
Logging Range (dBm) -63 to +2
Frequency Flatness(dB) +/- 2.5 (max) @ 25°C
+/- 3.0 (max) over temp
VSWR 2.3:1
Log Linearity (dB) Deviation from Best Fit Straight Line:
+/- 1.5 (max) @ 25
+/- 1.0 (80% band)

Over temperature:
+/- 2.0 (max)
+/- 1.5 (80% band)
Log Slope (mV/dB) For Linerity Measurement For Linearity: 25 +/- 1.0 mV/dB
For Log Accuracy: 25 mV/dB
Rise Time (nS) 15 (max)
10 (typ)
Fall Time (nS) 60 (max)
40 (typ)
Power Supply Current (mA) +12 (VDC) 600
Power Supply Current (mA) -12 (VDC) 150
Coupling DC
Video Load (ohms) 93 +/- 1
Operating Temperature (°C) -20 to +71 (Extended Temperature Range Available)
Size Figure 1
