RF & Microwave Amplifiers

Microwave Amplifier Assemblies

Features

    • Wide Band Frequency Coverage 1 to 40 GHz
    • Multi-channel Switchable Input Control
    • Ruggedized Packaging Options

Description

AKON has developed a series of frontend LNA assemblies with some options frequently asked by customers. The units feature a built-in Band Pass filters and SPNT Switch. Input switch can be optionally selected from SP2T to SP4T. Built-in oscillators can be added for spot frequency calibration. We can package one to four channels in a single package.

AKON products are designed to withstand the demanding environments of Military, Space and Civilian applications. Our compact and ruggedized products are designed to handle stringent mechanical shock/vibrations, temperature cycling, altitude and temperature extremes.

Reliability is a key feature of AKON products and to ensure this we perform ESS testing on all of our products. AKON offers an off-the-shelf screening option called its “H“ series, per Mil-STD-883 level B that is available on all of its RF & Microwave Components. For custom electrical, mechanical, and screening options, please contact AKON Sales: sales@akoninc.com (or) 408-432-8039.

SPECIFICATIONS
Model Number Frequency (GHz) Gain (dB) Flatness (± dB) Noise Figure (Nom.) Power Out (dBm) Power Supply Configuration Options Pkg. EAR99/ ITAR Select Product
A25-MH292 1-18 20 +/- 1.5 (Nom.)
+/- 2.0 (Max.)
8 +20 +/- 12V Switch
Noise
# Channels
D, T, S, N EAR99
A25-MH293 2-18 20 +/- 1.5 (Nom.)
+/- 2.0 (Max.)
8 +20 +/- 12V Switch
Noise
# Channels
D, T, S, N EAR99
A25-MX271 2-6 20 +/- 1.0 (Nom.)
+/- 1.5 (Max.)
8 +20 +/- 12V Switch
Noise
# Channels
D, T, S, N EAR99
A25-MX294 6-18 20 +/- 1.5 (Nom.)
+/- 2.0 (Max.)
8 +20 +/- 12V Switch
Noise
# Channels
D, T, S, N EAR99
A25-MX309 18-26 20 +/- 1.5 (Nom.)
+/- 2.0 (Max.)
10 +20 +/- 12V Switch
Noise
# Channels
D, T, S, N EAR99
A25-MX327 26-40 20 +/- 2.0 (Nom.)
+/- 2.5 (Max.)
10 +20 +/- 12V Switch
Noise
#Channel
D, T, S, N EAR99
A25-MX326 18-40 20 +/- 2.0 (Nom.)
+/- 2.5 (Max.)
10 +20 +/- 12V Switch
Noise
# Channels
D, T, S, N EAR99
Note: You can select different models and submit inquiry or custom quote request with help of different options available at bottom of page.

Customer Program

JPL - MIRO (Complex Integrated Microwave Assembly)
JPL - MLS (complex Converter Assembly)
AEG - Germany FL-1800 (Electronic Counter Measure)
CSIST - Shipboard Radar Update
Raytheon - SLQ - 32
BAE/Sanders - USM - 406C (Test Set)
BAE/Sanders - USM - 464 (Test Set)
US Navy - SAR - Synthetic Aperture Radar TR Modules
NAVSEA/Envisioneering - SEAPORT-e Program (Tuners)
Lockheed Martin - AEGIS
SEARAM - Rolling Airframe Missile
Brazilian Navy
DSTO Australia
Anaren - Canadian F18
Ford - HARM Missile Seeker
ITT - ASPJ (Airborne Self Protect Jammer) IDECM (Integrated Digital Electronic Counter)
Japan - FSX, Several RWR (Radar Warning Receiver)
BAE/Loral - ALR - 56C (F15 Fighter) RWR
BAE/Loral - ALR - 56M (F16 Fighter) RWR
BAE/Loral - ALQ - 131 (Pod Mounted Jammer)
Turkish F-16 - Front End Converters SPEWS II
DRS - Euro Fighter Test Set
BAE/Loral - ALR - 56V - F15 (RWR Update)
Northrop Grumman - JSTARS
Northrop Grumman - ALQ - 188 (Electronic Attack Training Pod)
Raytheon - ALQ - 142 (LAMPS Helicopter)
Electronica (Italy)
Government of India - Aircraft Radar
DSTO (Australia)
