High Speed SDLVAs with Limited RF Output

Features

    • Limited RF Output
    • Flat Frequency Response
    • Excellent Log Linearity
    • Excellent Temperature Performance
    • DC Coupled
    • EAR 99 Export Classification

Description

AKON Introduces a complete line of 70 dB dynamic logging range SDLVAs with limited output.  This line of microwave high speed SDLVAs utilizes thin-film microelectronics hybrid technology, making it well suited for harsh invironments.

AKON products are designed to withstand the demanding environments of Military, Space and Industrial applications. Our compact and ruggedized products are designed to handle stringent mechanical shock/vibrations, temperature cycling, altitude and temperature extremes.

Reliability is a key feature of AKON products and to ensure this we perform ESS testing on all of our products.  AKON offers an off-the-shelf screening option called its “H“ series, per Mil-STD-883 level B that is available on all of its RF & Microwave Components. For custom electrical, mechanical, and screening options, please contact AKON Sales: sales@akoninc.com (or) 408-432-8039.

Model Number A15-MH139 A15-MH137 A15-MH138 A15-MH155-1
Frequency Range(GHz) 2-6 6-18 0.5-2 2-18
T.S.S(dBm) -73 -73 -73 -73
Logging Range (dBm) -70 to 0 -70 to 0 -70 to 0 -70 to 0
Limited Output (dB) +13 +/- 2 dB +15 +/- 3 dB +13 +/- 2 dB +13 +/- 3 dB
Frequency Flatness(dB) +/- 1.5 +/- 2.0 +/- 1.5 +/- 3.0
VSWR 2.0:1 2.0:1 2.0:1 2.0:1
Log Linearity (dB) +/- 1.0 +/- 1.0 +/- 1.0 +/- 1.0
Log Accuracy (dB) (over termperature at a given frequency) +/- 2.5 +/- 3.0 +/- 2.5 +/- 3.0
Log Slope (mV/dB) For Linerity Measurement 25 25 25 25
Rise Time (nS) 10 10 10 10
Recovery Time (nS) (90% to +/- 1.0 dB of Baseline) 60 60 60 60
Propagation Delay (nS) (50% RF to 10% Video) 10 10 10 10
Power Supply Current (mA) +12 (VDC) 650 750 650 750
Power Supply Current (mA) -12 (VDC) 150 150 150 150
Coupling DC DC DC DC
Video Load (ohms) 93 +/-1 93 +/-1 93 +/-1 93 +/-1
Size Figure 1 Figure 2 Figure 3 Figure 2
Operating Temperature (°C) -20 to +85 -20 to +85 -20 to +85 -20 to +85
Select Product
Note: You can select different models and submit inquiry or custom quote request with help of different options available at bottom of page.

AKON, Inc. and it’s affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
All products are measured in 50-ohm system, over a temperature Range of -20° to +85° C.
