Power Dividers/Combiners

DC - 40 GHz Resistive Power Dividers/ Combiners

Features

    • Low Insertion Loss
    • Excellent Amplitude Balance and Phase Balance
    • Wide Band Frequency Coverage
    • Compact and Ruggedized Packaging
    • Package Options: SMA, 2.9mm

Description

AKON’s product line of Resistive Microwave Power Dividers/Power Combiners operate over a frequency range of DC - 40 GHz. AKON utilizes thin film substrates with resistive networks that provide excellent insertion loss, flatness and VSWR. This design construction offers surperior amplitude and Phase Balance between output ports.

AKON products are designed to withstand the demanding environments of Military, Space and Industrial applications. Our compact and ruggedized products are designed to handle stringent mechanical shock/vibrations, temperature cycling, altitude and temperature extremes.

Reliabilty is a key feature of AKON products and to ensure this we perform ESS testing on all of our problems. AKON offers an off-the-shelf screening option called it’s “H“ series, per Mil-STD-883 level B that is available on all of its RF & Microwave Components. For custom electrical, mechanical, and screening options, please contact AKON Sales: sales@akoninc.com (or) 408-432-8039.

Model Number A40-MH050 A40-MH051 A40-MH052
Frequency Range(GHz) DC-40 18-40 DC-20
Insertion Loss (dB) 1.8 1.8 1.5
Output Isolation P to P (dB) 13 13 13
VSWR (max) 2.0:1 2.0:1 2.0:1
Amplitude Balance (dB) 1 1 1
Phase Balance (º) 12 12 12
Max Input Power* (dBm) 30 30 30
Pkg. 2.9mm 2.9mm SMA
EAR99/ ITAR EAR99 EAR99 EAR99
Select Product
Note: You can select different models and submit inquiry or custom quote request with help of different options available at bottom of page.

AKON, Inc. and it’s affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
All products are measured in 50-ohm system, over a temperature Range of -54° to +85° C.
* Max power @ 2.0:1 MAX VSWR +25° C.
**In addition to 6.0 dB theoretical loss.
