Tuners

Wideband Microwave Tuner 1 - 18.0 GHz

Features

    • TYPE 1 TUNER
    • 1 - 18 GHz INPUT FREQUENCY
    • 65 dB INPUT DYNAMIC RANGE
    • 4 INPUT CHANNELS
    • 77.6 WATTS POWER CONSUMPTION
    • SIZE: 9.2” x 5.9” x 1.7”
    • WEIGHT 3.0 KG

Description

AKON’s 1 to 18 GHz Wideband Microwave Tuner A90-MX010 is preceded by a front-end low noise amplifier (limiter - low noise amplifier - 10 meter cable - equalizer - bias tee on both sides of the RF cable). (FEA is separately specified). The net front-end FEA gain is 20 dB with 5 dB maximum (4.0 dB nominal) noise figure and +23 dBm minimum output power. The 10 meter cable with equalizer and bias tee has 8.0 dB loss. Thus the input dynamic range of -65 to 0 dBm is translated to -55 dBm to +10 dBm at the input of the tuner. AKON is qualified to MIL-I-45208 Quality System requirements by agencies of the U.S. D.O.D. and leading military OEMs. Screening to requirements of MIL-STD-883 is available. All specifications described below are over the full operating temperature.

SPECIFICATIONS
Model Number A90-MX010
Number of Input Channels 4 Total (J1, J2, J3, J4)
Number of Output Channels 12 Total: 4 - To Narrow Band Receiver;
4 - To Bite Input;
4 - To Vid 1,2,3,4
Output Frequency Data 14 bits + 1 bit (Signal Present)
Output: Monitor Prior to DFD (dBm) -51 to +6
Isolation (dB) 60 (min); 65 (nom)
Harmonics (dBc) -8 (min)
Spurious (dBc) -50 (min)
Frequency Range(GHz) 1 to 18
Processing Bands (GHz) 1 – 2, 2 – 6, 6 – 10, 10 – 14, 14 – 18
Filter Rejection 15% from band edges (dBc) -65
Input RF Processing Range (dBm) -53 to +12
Input Equivalent Dynamic Range at FEA Input (dBm) -65 to 0
T.S.S @ FEA Input (dBm) -72 (nom)
Input Log Dynamic Range (@FEA Input) (dBm) -72 to 0
Log Slope (mV/dB) 25
Absolute accuracy of power measurement (dB) +/- 2.0 (typ); +/-3.0 (max)
Channel to Channel Isolation (dB) 65
Input VSWR 2.0:1
Log Linearity over frequency and temperature (dB) +/-1.5
Pulse Rise Time (10% - 90%) (nS) 25
Pulse Settling Time (nS) 40
Recovery Time (nS) 75
Input Control Bits Total 7 Bits:
3 Band Select
2 Input SW Control
1 INT/EXT SW Control Select
1 DFD INT/EXT Trigger
Power Supply(VDC) +12 @1.0A; +8 @ 6.2A; -8 @ 2.0A
Select Product
Note: You can select different models and submit inquiry or custom quote request with help of different options available at bottom of page.

Customer Program

JPL - MIRO (Complex Integrated Microwave Assembly)
JPL - MLS (complex Converter Assembly)
AEG - Germany FL-1800 (Electronic Counter Measure)
CSIST - Shipboard Radar Update
Raytheon - SLQ - 32
BAE/Sanders - USM - 406C (Test Set)
BAE/Sanders - USM - 464 (Test Set)
US Navy - SAR - Synthetic Aperture Radar TR Modules
NAVSEA/Envisioneering - SEAPORT-e Program (Tuners)
Lockheed Martin - AEGIS
SEARAM - Rolling Airframe Missile
Brazilian Navy
DSTO Australia
Anaren - Canadian F18
Ford - HARM Missile Seeker
ITT - ASPJ (Airborne Self Protect Jammer) IDECM (Integrated Digital Electronic Counter)
Japan - FSX, Several RWR (Radar Warning Receiver)
BAE/Loral - ALR - 56C (F15 Fighter) RWR
BAE/Loral - ALR - 56M (F16 Fighter) RWR
BAE/Loral - ALQ - 131 (Pod Mounted Jammer)
Turkish F-16 - Front End Converters SPEWS II
DRS - Euro Fighter Test Set
BAE/Loral - ALR - 56V - F15 (RWR Update)
Northrop Grumman - JSTARS
Northrop Grumman - ALQ - 188 (Electronic Attack Training Pod)
Raytheon - ALQ - 142 (LAMPS Helicopter)
Electronica (Italy)
Government of India - Aircraft Radar
DSTO (Australia)
