Fast Rise & Fall Time SDLVA 2 - 18 GHz; 60 dB

Features

    • FAST RISE AND FALL TIMES
    • EXCELLENT LINEARITY
    • COMPUTER TUNED AND TESTED
    • PRODUCTION READY
    • SIZE: 3.20” x 1.85” x 0.40”

Description

AKON is a leading manufacturer of RF/microwave components and subsystems for military, space and commercial applications. AKON’s product line includes high reliability, custom integrated microwave assemblies, DFD receivers, microwave receiver front-ends, RF switching matrices, frequency synthesizers, custom LO assemblies, frequency converters, RF switches, digitally controlled attenuators, miniature RF filters and switches, and microwave amplifiers covering 0.5 - 18.0 GHz frequency range (up to 40.0 GHz for some applications).

Model A15-MH069 is an ultra-fast miniature SDLVA. In slightly over 2.0 cubic inches, the unit features 60 dB dynamic range and exceptionally fast 40 nanosecond fall time.

SPECIFICATIONS
Model Number A15-MH069
Frequency Range(GHz) 2.0-18.0
Dynamic Range(dBm) 60
T.S.S(dBm) -66
Logging Range (dBm) -60 to 0
Frequency Flatness(dB) +/- 2.0 (max);
+/- 1.75 (typ)
Log Linearity (dB) +/- 1.5 (max);
+/- 1.0 (typ)
Log Slope (mV/dB) For Linerity Measurement 15
Rise Time (nS) 10
Fall Time (nS) 40
Propagation Delay (nS) (50% RF to 10% Video) 10
Recovery Time (nS) (90% to +/- 1.0 dB of Baseline) 125 (typ);
200 (max)
Power Supply(VDC) +12 @ 500mA;
-12 @ 125mA
Coupling DC
Operating Temperature (°C) -20 to +71
VSWR 2.0:1 (max)
