AKON’s product line of Wilkinson Microwave Power Dividers/Power Combiners operate over a frequency range of 10 - 40 GHz. AKON utilizes Wilkinson topology on thin film substrates that provide excellent insertion loss, flatness and VSWR. This design construction offers surperior amplitude and Phase Balance between output ports.
AKON products are designed to withstand the demanding environments of Military, Space and Industrial applications. Our compact and ruggedized products are designed to handle stringent mechanical shock/vibrations, temperature cycling, altitude and temperature extremes.
Reliabilty is a key feature of AKON products and to ensure this we perform ESS testing on all of our problems. AKON offers an off-the-shelf screening option called it’s “H“ series, per Mil-STD-883 level B that is available on all of its RF & Microwave Components. For custom electrical, mechanical, and screening options, please contact AKON Sales: sales@akoninc.com (or) 408-432-8039.
| Model Number | A40-MH059 | A40-MH069 |
|---|---|---|
| Frequency Range(GHz) | 10 - 40 10 - 20 GHz 20 - 26 GHz 16 - 40 GHz |
10 - 40 10 - 20 GHz 20 - 26 GHz 16 - 40 GHz |
| Insertion Loss (dB) | 0.7 1 1.8 |
0.9 1.2 1.8 |
| Output Isolation P to P (dB) | 19 16 13 |
19 16 13 |
| VSWR (max) | 1.6:1 1.75:1 1.95:1 |
1.6:1 1.7:1 2.0:1 |
| Amplitude Balance (dB) | 0.35 0.55 0.85 |
0.35 0.55 0.85 |
| Phase Balance (º) | 6 7 12 |
6 7 12 |
| Max Input Power* (dBm) | 30 | 30 |
| Pkg. | 2.9mm | 2.9mm |
| EAR99/ ITAR | EAR99 | EAR99 |
