AKON has developed a new series of Log IF Amplifiers that operate over a variety of bands between 0.5 to 2 GHz frequency range. This new line offers excellent linearity over a dynamic logging range of dB and comes with a compact ruggedized package.
AKON products are designed to withstand the demanding environments of Military, Space and Industrial applications. Our compact and ruggedized products are designed to handle stringent mechanical shock/vibrations, temperature cycling, altitude and temperature extremes.
Reliability is a key feature of AKON products and to ensure this we perform ESS testing on all of our products. AKON offers an off-the-shelf screening option called its “H“ series, per Mil-STD-883 level B that is available on all of its RF & Microwave Components. For custom electrical, mechanical, and screening options, please contact AKON Sales: sales@akoninc.com (or) 408-432-8039.
| Model Number | A17-OH010 | A17-1H011 | A17-MH012 |
|---|---|---|---|
| Frequency Range(GHz) | 0.5 -1 | 1-2 | 0.5-2 |
| T.S.S(dBm) | -72 | -72 | -72 |
| Logging Range (dBm) | -65 to 0 | -65 to 0 | -65 to 0 |
| Frequency Flatness(dB) | +/- 1.0 | +/- 1.0 | +/- 1.25 |
| Log Linearity (dB) | +/- 1.0 | +/- 1.0 | +/- 1.0 |
| Temperature Variation (dB) | +/- 1.0 | +/- 1.0 | +/- 1.0 |
| Rise Time (nS) | 10 | 10 | 10 |
| Recovery Time (nS) (90% to +/- 1.0 dB of Baseline) | 60 | 60 | 60 |
| Propagation Delay (nS) (50% RF to 10% Video) | 10 | 10 | 10 |
| Log Slope (mV/dB) | 15 | 15 | 15 |
| Power SupplyCurrent (mA) +15 (VDC) | +300 (typ) | +300 (typ) | +300 (typ) |
| Power SupplyCurrent (mA) -15 (VDC) | -115 (typ) | -115 (typ) | -115 (typ) |
| Coupling | DC | DC | DC |
| Operating Temperature (°C) | -40 to +85 | -40 to +85 | -40 to +85 |
| VSWR | 2.0:1 | 2.0:1 | 2.0:1 |
| Size | Figure 1 | Figure 1 | Figure 1 |
