Digital Frequency Discriminator

Digital Frequency Discriminator 4.3-5.3 GHz

Features

    • 4.3 - 5.3 GHz FREQUENCY RANGE
    • HIGH SENSITIVITY
    • MULTIPLE SIGNAL HANDLING
    • TTL COMPATIBLE
    • 300 nS PROCESSING TIME
    • 0.25 MHz FREQUENCY ACCURACY

Description

AKON is a leading manufacturer of RF/microwave components and subsystems for military, space and commercial applications. AKON’s product line includes high reliability, custom integrated microwave assemblies, DFD receivers, microwave receiver front-ends, RF switching matrices, frequency synthesizers, custom LO assemblies, frequency converters, RF switches, digitally controlled attenuators, miniature RF filters and switches, and microwave amplifiers covering 2.0 - 18.0 GHz frequency range (up to 40.0 GHz for some applications). AKON is qualified to MIL-I-45208 Quality System Requirements by agencies of the U.S. Department of Defense and by leading foreign and domestic military OEMs. All specifications are valid over the full operating temperature unless otherwise indicated.

SPECIFICATIONS
Model Number A55-MX008
Frequency Range(GHz) 4.3-5.3
Unambiguous Frequency Range (GHz) 3.8-5.8
Frequency Resolution (MHz) 0.125 (14 bits)
Frequency Accuracy (MHz) ( RMS) 0.25
Trigger Internal and External
Sensitivity (dBm) -55
Dynamic Range(dBm) 50
Processing Time (nS) 300 (from RF leading edge)
Pulse Width Range (nS) 100 to CW
Binary Zero (MHz) 3776
Frequency Value 3776 + output data (decimal equivalent)*0.125 MHz
Data for Input Frequency < 4290 MHz 3FFF (hex)
Data for Input Frequency > 5310 MHz 3FFF (hex)
Input RF SNR (dB) 25
External Trigger TTL Pulse 100 nS
Flags 1) CW Flag: TTL High if CW signal is detected
2) Signal Present: 100 nS pulse output 100 nS delay
Power Supply(VDC) +15V, -15V and +5V
Operating Temperature (°C) 10 to 40
